Blue Flasher

Blue Flasher

£2,600.00

The first Blue&Me module repairer on the market!

NO SOLDERING, TEMPLATE WITH QUICK HOOK

Template specifically designed to guarantee connection via test microprobes directly on the JTAG connector of the microcontroller. Specific power connectors for Blue&Me type Laubernhorn (Fiat Group) and for Blue&Me Chrysler. Template designed for both types of boards.

PROXY CONFIGURATION RECOVERY AND SAVING

The Proxy data represent the association between the vehicle body computer and the Blue&Me installed. Keeping this data unaltered is essential to ensure that the repair is "Plug&Play". It means that the Blue&Me can be reassembled in the car without the need to perform a proxy alignment with a diagnostic tool. It is therefore possible to make repairs even remotely for other colleagues.

DRIVERLESS INTERFACE FOR WINDOWS PC

The tool is recognized by Windows as a USB stick, so there is no need to install any drivers to ensure it works.

(Internet connection required)

CAN DIAGNOSTIC PROTOCOL WITH INTEGRATED FUNCTIONING TEST

CAN interface integrated in the product, able to verify the correct functioning of the Blue&Me and to display the basic diagnostic information.

READING AND WRITING SPEED

In less than 3 minutes it is possible to write the 128 MBytes of the NAND FLASH!

MULTIPLE FUNCTIONS ON NAND MEMORY

Full NAND Flash read, erase, save and write functions.

AUTOMATIC MEMORY IDENTIFICATION

NW140 / NQ278 / K9F1 memory mounted in Blue&Me (Lauberhorn type) with memory type MT29F1G08AXXXXXX of 1GBit size in 63 VFBGA format.

NW190 memory mounted in Blue&Me of Fiat Freemont/ Lancia Thema/ Dodge Journey/ Chrysler 300C with memory type MT29F4G08ABitADAH4 in 63 VFBGA format.

BLUE&ME ECU MODELS SUPPORTED

Blue Flasher supports all Blue&Me models first generation with PLD XILINX XC35400 microprocessor and second generation with STA2062 microprocessor.

GUIDED REPAIR PROCEDURE

No skills required! The software automatically chooses the file to write to repair the ECU. At the end, a CAN operation check of the Blue&Me module is carried out.

REQUIRED TOOLS:

Regulated power supply 12V / 5A (minimum).

Windows 10 PC with internet connection.

2GB of free disk space.

Blue&Me models supported:

STA2062 microprocessor

Memory: NW140 / NW190 / NQ278

Most common problems due to malfunctioning software:

Blinking odometer

USB port not working

Bluetooth connection not working

Satnav not working

Steering wheel controls working only at times

Speakerphone not working

Proxy alignment not possible

Vehicle battery is completely discharged

Error U1733 from telematic info node

Error P0022 from convergence node control unit on CAN line

Automatic repair wizard

With just a couple of clicks it's possible to perform a full software repair.

There's no need to have a working memory dump file or to perform a proxy alignment at the end.

Vehicles supported

Abarth:

Abarth 500 until 2016

Abarth Grande Punto

Abarth Punto Evo

Alfa Romeo:

Alfa Romeo 147 from 2008

Alfa Romeo 159

Alfa Romeo Brera

Alfa Romeo Giulietta until 2013

Alfa Romeo GT from 2008

Alfa Romeo MiTo until 2013

Alfa Romeo Spider

Chrysler:

Chrysler 300C

Citroen:

Citroen Nemo

Citroen Relay

Dodge:

Dodge Journey

Fiat:

Fiat 500

Fiat Bravo

Fiat Croma

Fiat Freemont

Fiat Grande Punto

Fiat Idea

Fiat Linea

Fiat Panda until 2016

Fiat Punto until 2016

Fiat Punto Evo

Fiat Qubo until 2016

Fiat Professional:

Fiat Fiorino until 2016

Fiat Doblò until 2014

Fiat Ducato until 2014

Ford:

Ford Ka Second generation 2008 - 2016

Lancia:

Lancia Delta

Lancia Musa

Lancia Ypslon

Lancia Thema

Opel Vauxhall:

Opel Vauxhall Combo

Peugeot:

Peugeot Bipper

Peugeot Boxer

Blueflasher - Guided repair procedure demo - Click here

Add To Cart
