TDB500 Vehicle key transponder cloning - Remote key tester
TDB500 Vehicle key transponder cloning - Remote key tester
TDB500 Clone Wizard is a simple to use Key Cloning tool.
Includes 25 Transponders
Payback can be as quick as just 15 keys!
Cloning
Using it's own unique coloured transponders
Red - Blue - Green - Purple
it takes all the guess work out of which transponder to use.
Supported by the Wiki Clone support site, found at www.wikiclone.com the user can quickly see if the key is cloneable without the key being present.
If the key is present it becomes an even simpler task thanks to the Easy Clone function via the EASY MODE.
Simply read the key and the tester will prompt which colour transponder is required.
Fixed coded and many crypto transponders require just the working key.
More advanced Transponders require a sniffing process at the car.
Current cloning coverage
TEXAS 4C, 4D (40bit) (80bit to be released at later date)
PHILLIPS / NXP ID33, ID40 (unlocked), ID41 ,ID42, ID44 (unlocked), ID45, ID46
MEGAMOS ID13, ID48 (WILL BE ADDED AS AN UPDATE PACKAGE)
TEMIC 11, 12
Remote Testing
The TDB500 has a built in remote testing function that allows the user to see if the remote is working, what frequency it is running on and also if it is ASK or FSK.
Advanced Functions - EXPERT MODE
For the more advanced tasks, the TDB500 has an EXPERT MODE
This allows more in-depth transponder interrogation and the ability to edit pages, compare data and generate transponders.
Advanced functions work inline with the TDB1000 Key Programmer such as Fiat Precoding.
More advanced functions will be introduced and released.
MAIN FEATURES :
TOUCH SCREEN LCD DISPLAY
REMOVABLE TRANSPONDER CLONING TRAY TOUCH SCREEN PEN
RECHARGEABLE BATTERY POWERED
RF REMOTE TEST FREQUENCY TEST
USB2.0
BLUETOOTH CONNECTION
WI FI CONNECTION
The Wifi connection will allow the TDB500 Clone Wizard to connect to a mobile hotspot or router so that it is future proof to allow larger calculations via the Clone Wizard server without the need to connect to a PC or Laptop.
Kit Contents
1x TDB500 Clone Wizard Machine
1x Carry Case
1x Stylus Pen
1x Transponder Case
5x TDB510 - BLUE Transponder
5x TDB520 - RED Transponder
5x TDB540 - GREEN Transponder
5x TDB550 - PURPLE Transponder
